1. Non-destructive drying and cleaning, can be used for Mofs, gels, biological samples, chips and other samples drying and cleaning ；

2. New automatic design, touch screen control, no manual duty operation；

3. Built-in a variety of material experiment flow options, support custom personalized processing solutions；

4. Vertical sample chamber with top fill and bottom drain to facilitate media discharge and sample placement；

5. High pressure sample chamber with window, volume 30-200ml optional, larger volume can be customized；

6. The normal working pressure of the instrument is 5-9MPa, and the factory testing system can withstand 15MPa (2150psi) to ensure safety and reliability。

7. The instrument is equipped with automatic overpressure relief system to ensure pressure control。

8. Automatic temperature and pressure control, with a pressure module to maintain system pressure stability；

9. The top of the sample chamber is provided with an observation window and lighting to facilitate the observation of liquid filling status；

10. Complete filtration system with external two-stage filter and built-in 0.5μm filter to protect samples and trim valves；

11. A variety of sample holders are suitable for materials with different characteristics；

12. All lines and valves are made of 316 stainless steel and are suitable for supercritical CO2 and ethanol；

13. Internal thermal insulation design, reduce co2 consumption, energy saving and environmental protection。

14. Sturdy, corrosion-resistant housing with power supply and heating indicator。

　　With standard accessory：

　　Flexible high-pressure LCO2 line, 1.5 m, connecting cylinders to instruments；

　　Two sets of external filters (filtration accuracy: 2 and 0.5um), supporting high pressure hose；

　　Powder sample and block sample holder；

　　2 anti-static emptying pipelines, each 1.5 meters；

　　Spare sample chamber seal ring (2)；

　　Installation tool set；

　　User manual and user guide；

　　One year warranty and free technical support for life。

　　Users need to equip：

　　Carbon dioxide in cylinder (with siphon)；

　　99.9%Pure ethanol (or other suitable medium)）。
