1. Non-destructive drying and cleaning, which can be used for drying and cleaning a variety of samples such as Mofs, gels, biological samples, wafer sheets, etc.;

2. Fully automatic design, touch screen to display the progress of the drying process, program control, color change according to the progress of the experiment, accompanied by experimental time, real-time pressure, temperature, flow data and other displays, can grasp the details and changes of the experiment throughout the process;

3. Built-in a variety of material experimental processes are optional, and customized personalized processing schemes are supported;

4. Vertical sample chamber with top filling and bottom emptying, which is conducive to media discharge and sample placement;

5. High-pressure sample chamber with window, volume 30, 100, 150, 300, 500 optional, larger volume can be customized;

6. The normal working pressure of the instrument is 0-12MPa, and the factory detection system has a withstand pressure of 15MPa (2150psi), which is safe and reliable.

7. The instrument is equipped with an overpressure automatic pressure relief system to ensure that the pressure is controllable.

8. Automatically control the temperature and pressure, and be equipped with a pressure module to maintain the stability of the system pressure;

9. The top of the sample chamber is equipped with an observation window and lighting, which is convenient for observing the liquid filling state;

10. Complete filtration system, external two-stage filter and built-in 0.5μm filter to protect samples and fine-tuning valves;

11. A variety of sample holders are suitable for materials with different characteristics;

12. ll ipelines and valve bodies are made of 316 stainless steel, which are suitable for supercritical carbon dioxide and ethanol;

13. Built-in compressor refrigeration and sample cell insulation, no need for water bath cooling system and additional CO2 refrigeration;

14. Sturdy and corrosion-resistant cabinet with power and heating indicators.

Standard Accessories:

Flexible high-pressure LCO2 pipeline, 1.5 m, connecting cylinders and instruments;

External filter (filtration accuracy: 0.5um), equipped with high-pressure hose;

powder sample and bulk sample holders;

2 anti-static draining pipelines, each 1.5 meters;

spare sample chamber sealing ring (2);

A set of installation tools;

User manuals and user guides;

Lifetime free technical support.
